Challenge Titan 200BC Semi-Automatic Hydraulic Paper Cutter - CMC-200BC

$11,595.00
In stock
SKU
CMC-200BC

The Challenge Titan 200M paper cutter features a manual backgauge with hydraulic cutting and clamping. Capable of cutting 3.25-inch lifts, this cutter offers excellent productivity, capacity, ease of operation and safety. The plastic safety shield and dual cut buttons offer increased safety features with powerful cutting capabilities.
FREE ground shipping on this item!
Contact CFS for best price, click to reach us or call toll-free: 1-888-237-3221

The Titan 200BC is a 20 inch wide paper cutter featuring a manually-adjusted backgauge (lockable) with hydraulic clamp pressure and blade operation. The easy-to-read LED digital display allows for ultimate control along with a line light cut position indicator and push button controls, the 200M paper cutter provides easy use as well as protection. In order to cut, the safety shield must be closed, and then with the push of 2 buttons (with both hands), the blade engages. The Titan 200M is the ideal cutter for a mid-to-high production facility that requires high-speed production, durability and superior safety.

Features Include:

  • 20" Cutting Width, 3-1/4" Clamp Opening
  • Hydraulic Clamping & Cutting
  • Easy to Read LED Digital Display
  • Line Light Cut Position Indicator
  • Hydraulic Motor Runs Only During Cutting Cycle
  • Plexiglas Safety Shield (shown)
  • Rear Table Safety Cover
  • Dual Cut Buttons TO Activate Cutting Cycle
  • Heavy Duty Casters Cast Iron and Steel Construction
  • Plugs Into Standard 110V Electrical Socket
  • 1 Year Warranty

Includes: Inlaid carbon alloy tool steel knife, 3 plastic cutting sticks, jogging aid, owner's manual,, tool kit, knife-change safety holder assembly.
Options: Independent Mechanical Foot Pedal Clamping, Side Tables (12" x 19"), False Clamp Plate, Light Beam Safety Sensors.

Titan 200-BC Semi-Automatic Cutter Specifications
Cutting Width 20"
Cutting Height 3.25" (3" with False Clamp)
Clamping Method Hydraulic
Backgauge Operation Manual - Handcrank Wheel
Min. Clamping Force 1250 lbs.
Max. Clamping Force 2500 lbs.
Narrow Cut 0.5" w/out False Clamp; 1-7/8" w/False Clamp
Cutting Length behind Knife 20"
Table Length in front of Knife 16"
Table Height 36"
Electrical 120V, 60 Hz, 12 Amp (15 Amp Service Size)
Dimensions 36" W x 53" H x 50-7/8" D
Weight 755 lbs.
Shipping Weight 980 lbs.
Warranty 1 Year Defective Parts
